Prism Free Standing Gantry and Portable Hoist Package

Prism Free Standing Gantry and Portable Hoist Package

The Prism Free Standing Gantry and Portable hoist can be purchased together as a package, at a discounted price this will be saving you money. The Free Standing Gantry System is designed to provide both the carer and user a safe, stable hoist track in places where fixed hoists are not available or whether a portable solution such as travelling is needed. It is a cost effective solution that is extremely easy to transport  and assemble in minutes by either 1 person or 2 without the need of tools. The Prism Gantry System has a safe working load of 200 kg (31 stone). It caters for both the patient and carer providing a safe and dignified experience. The Prism Free Standing Gantry and Hoist can be used to lift and transfer individuals  from a bed to chair, chair to bed etc. The Prism CP200 Portable Track Hoist offers exceptional versatility and cost savings as it can be quickly removed and put onto another fixed/gantry system. The quick release system on the top and bottom of the unit allows it to be swapped quickly. The Prism CP200 is compact and quiet in use. Whilst offering a start/stop function for user comfort. The CP200 can provide up to 60 lifts on a single charge and also has a safe working load of 200 kg. The lightweight aluminium (4.5 kg) makes it easy to carry when travelling.

Manufactured in the UK and 1 Year Warranty

Specifications

Prism Gantry Hoist Specifications:

Max Safe Working Load: 200 kg

Minimum Useable Track Length: 1900 mm

Maximum Useable Track Length: 2825 mm

Minimum Unit Width 2445 mm

Minimum Unit Width: 3387 mm

Minimum Ceiling Height: 2141 mm

Maximum Gantry Height: 2508 mm

Foot length: 870 mm

Total Weight (Boxed): 47.5 kg

Unit weight (inc Trolley): 44 kg

Track / Trolley Weight: 16 kg

Upright weight (x2): 10.5 kg each

Feet weight (x2:) 3.5 kg each

Height adjustments: 75 mm

Warranty: 1 year

Prism Portable CP200 Hoist Specifications:

Max Safe Working Load: 200 kg

Hoist Case: Non Flammable ABS Plastic

Length: 208 mm

Width: 177 mm

Height: 149 mm

Weight: 4.5 kg (Hoist only)

Rail Transfer: Manual

Hoisting Range: Up to 2100 mm

Lifting Speed: (unloaded) 35 mm/s

Lifting Speed: (100 kg loaded) 25 mm/s

Charger Input: 100- 240 V

Charger Output: 24 V - 1.33 amps

Emergency Stop: Electric

Hand Control:Electric 3 (Button)

Batteries: 2 x 12 V - 3.3 Ah Nimh

In Track Charging: Not Available

Removable from Track: Yes

Duty Cycle: 15% use, 85% rest

Features

Gantry Hoist Features:

- High-strength lightweight aluminium

- 200 kg (440 lbs) max load

- 1.9-2.85 m (6.2-9.35 ft) adjustable track length

- 2.1-2.5 m (6.9-8.2 ft) adjustable height

- Stable 0.87 m (2.85 ft) feet

- Built-in easy-slide trolley

- Floor level adjusters

- Star Handle securing screws

- Safety latch to prevent uprights retracting

-Securing Bolts and lynch pins

- One (1) year warranty

Prism Portable CP200 Hoist Features:

- Compact lightweight aluminium chassis, total unit weight 4.5 kg without a carry bar.

- Capable of transferring a patient of up to 200 kg (440 lb)

- Up, down and emergency lowering controls on both hand controller and unit

- Power switch on rear of unit

- Auto power off after approximately 30 seconds of non- use to save battery 50-60 lifts per charge

- Integrated wall dock and charger

- QRS reacher and QRS carry bar

- Trolley Set (compatible with Prism Medical track systems)

LED indicators for:

Battery and error status, Sleep mode, Emergency lower, Temperature warning, Lifted weight is over capacity, Slack tape error and Charger fault
